By David Wren
Working with Hager UK, the latest version of the Hager CPD DB has now been raised to Hager 2023.
This new version of the CPD DB is up to date with the full ranges of breakers produced by Hager, including their ranges of AFDD-MCBs, plus the new AFDD-RCBOs with Type A RCD trips.
As per details below:
- The RCBO ranges, ADB Type B and ADC Type C both rated at 10kA. and fitted with Type AC earth trip RCD units, are now marked as Obsolete.
These breakers have been replaced with the newer ADA ranges of Type B and Type C RCBOs both rated at 10kA and equipped with Type A RCD earth trip units. - ARM 6kA MCB-AFDD added
- ARR 6kA RCBO-AFDD added
- ARC MCB-AFDD 10kA Type B added
- ARC MCB-AFDD 10kA Type C added
- Temperature Derate data added to Fuses, AFDDs, MCBs, RCBOs
- Discrimination tables added for combinations of upstream HDA and HHA MCCBs to downstream MCBs.
