by Garry Stockton
Top 10 reasons you can't see an Element in Revit
- Is the correct Workset being used?
- Is the view range set correctly to see the element required?
- Is the object hosted on an incorrect surface like a floor instead of a ceiling?
- Is there a filter applied to the view that is causing the element to be hidden?
- Is the detail level of the view set correctly? Some families are set not to show at Coarse.
- Try using the "Reveal Hidden Elements" tool in the view control bar.
- Is there a plan region in the view?
- Is the view "Discipline" set correctly?
- Is the element in the correct phase and is an appropriate phase filter set in the view to make it visible?
- Is the element part of a design option and perhaps that isn't the current option for that particular view?
