By Chris Turner
Although quite simple, I just thought I would share this really easy tip of constraining some sketched points so they are evenly spaced.
Using the Inventor dimensions, you can link and cross reference values quickly.
Check out my video below!
From this, you can even rename and export the parameter for use elsewhere in an assembly!
