By Chris Turner
I always get asked about having a list of what all the Vault Status Icons are and I previously blogged this a good few years ago.
With the recent Vault 2020 products released, there have been a few changes to the Vault Status Icons both in the Vault Client itself and the Vault CAD Add-ins.
A handy link to all of these in Vault Basic, Workgroup and Professional 2020 can be found here.
Both the old and new Vault Status Icons are shown.
http://help.autodesk.com/view/VAULT/2020/ENU/?guid=GUID-3621EE8C-4CC6-44F8-8111-314ADE6D2AB3
