By Clint Brown
In the video below, I show you how to create half section as well as quarter and three quarter section views in Inventor.
The workflow is identical for parts and Assemblies, see the image below for a view of the interface in the part environment.
The Article on Driving constraints which is mentioned in the video can be found here: https://www.cadlinecommunity.co.uk/hc/en-us/articles/201901101
