By John Flanagan
Understand the Trim Mode Options
The no trim mode setting allows me to place the fillet arc without deleting or trimming any of the existing elements.
Trim
Selected objects or line segments are trimmed to meet the endpoints of the fillet.
No Trim
Selected objects or line segments are not trimmed before the fillet is added.
The current value is stored in the TRIMMODE system variable.
